F# introduction

Motivation

Typical C# day

 1:
 2:
 3:
 4:
 5:
 6:
 7:
 8:
 9:
10:
11:
12:

public interface ILaboratoriesServiceContract
{
    Laboratory GetLaboratoryById(long id);

    IList<Laboratory> FindLaboratories(LaboratoryFilter filter);

    long AddLaboratory(Laboratory laboratory);

    bool UpdateLaboratory(Laboratory laboratory);

    bool DeleteLaboratory(long IdLaboratory);
}

actually, this interface has too many responsabilites (is not SOLID)

anyway, we can try to implement a smart solution

I said smart, because it was mine

ANYWAY

Wrap results that can fail

 1:
 2:
 3:
 4:
 5:
 6:
 7:
 8:
 9:
10:
11:
12:

public interface ILaboratoriesServiceContract
{
    SvcResult<Laboratory> GetLaboratoryById(long id);

    SvcResult<IList<Laboratory>> FindLaboratories(LaboratoryFilter filter);

    SvcResult<long> AddLaboratory(Laboratory laboratory);

    SvcResult<bool> UpdateLaboratory(Laboratory laboratory);

    SvcResult<bool> DeleteLaboratory(long IdLaboratory);
}

 1:
 2:
 3:
 4:
 5:
 6:
 7:
 8:
 9:
10:
11:
12:
13:
14:
15:
16:
17:
18:
19:
20:
21:

public class SvcResult<T>
{
    public T Value { get; private set; }

    public SvcResult(T value)
    {
        this.Value = value;
    }

    public SvcResult(T value, string error)
        : this(value)
    {
        if (!string.IsNullOrEmpty(error))
        {
            this.Errors = new List<string>();
            this.Errors.Add(error);
        }
    }

   // some code removed...
}

 1:
 2:
 3:
 4:
 5:
 6:
 7:
 8:
 9:
10:
11:
12:
13:
14:

public ActionResult Edit(long laboratoryId)
{
    var res = this.svc_laboratory.GetById(laboratoryId);
    if (res.HasErrors)
    {
        string msg = string.Join(System.Environment.NewLine, res.Errors.ToArray());
        return new HttpNotFoundResult(msg);
    }
    else return View("Form", new LayoutableModelBase()
    {
        Id = laboratoryId,
        Model = res.Value,
    });
}

Seems not so bad

but...

if you have to compose somehow the results of one service with another ones...

 1:
 2:
 3:
 4:
 5:
 6:
 7:
 8:
 9:
10:
11:
12:
13:
14:
15:
16:
17:
18:
19:
20:
21:
22:
23:

    public SvcResult<bool> Assign(MassiveFamilies assignation)
    {
        MassiveFamiliesBusinessRules rules = new MassiveFamiliesBusinessRules(assignation, context);
        if (!rules.AreValid())
        {
            return new SvcResult<bool>(false, rules.GetErrors());
        }
        else
        {
            foreach (int familyId in assignation.Ids)
            {
                //updating calibration by using selected status
                var family = svc_families.GetById(familyId);
                if (family.HasErrors || family.Value == null)
                    throw new ApplicationException("Impossible. There is no way to retrieve an unexisting family by id " + familyId);
                family.Value.CustomerId = this.context.Current.CustomerId;
                var res = svc_families.Create(family.Value);
                if (res.HasErrors) //throws
                    throw new ApplicationException(string.Join(" ", res.Errors));
            }
            return new SvcResult<bool>(true);
        }
    }

This is heavy, Doc

This is heavy, Doc! (Marty McFly, two days ago)

Enter F# magic

Enter F# magic

  • Expressiveness
  • Type Safety
  • Conciseness

Expressiveness

 1:
 2:
 3:
 4:
 5:
 6:
 7:
 8:
 9:
10:

let updateParameters (t:int) (s:int) (tps:Protected<Api.TranslatedProtocol>) =

    checkHash "concurrency error, someone changed the same protocol while you were editing it"
    >=> checkIntegrity "data integrity error, there are parameters that are not from this protocol"
    >=> validateIdentifiers
    >=> checkTranslationKeyNotDefault DEFAULT_TRANSLATION_KEY (sprintf "%s is not a valid TranslationKey" DEFAULT_TRANSLATION_KEY)
    >=> checkTranslationKeysUniques "duplicated TranslationKey in this protocol"
    >=> prepareChanges
    >=> Utils.applyChanges "unable to apply changes"
    >> Utils.log "prot updated" "prot not updated:" <| (t, s, tprot)

Expressiveness (2)

 1:
 2:
 3:
 4:
 5:
 6:
 7:
 8:
 9:
10:
11:
12:
13:
14:
15:
16:
17:

(* Query parser *)
let private pquery =
    pAll
    <|> pPlugin
    <|> pLeftAndRight
    <|> pKeyAndValue
    <|> pKey
    <|> pValue
    <|> pIdentifier
    <|> pName
    <|> pVersion
    <|> pNaive

let private filterPlugins q config =
    let pres = match run pquery q with
                    | Success(result, a, b) -> Some result
                    | Failure(error, _, _) -> None

Type Safety

1:
2:

let printmsg = sprintf "%d bottles of beer, standing on a wall"
in printmsg 42

Conciseness

 1:
 2:
 3:
 4:
 5:
 6:
 7:
 8:
 9:
10:

module Application =

    let registerDependencies () =
        (* DI ? We don't need DI where we are going *)
        let path = ProtocolsEditor.Infrastructure.Config.protocols_file_path
        let protocols = ProtocolsEditor.Application.ReadProtocols.getProtocols path
        ProtocolsEditor.Application.Repositories.Protocols.initializeRepo protocols.Value |> ignore

        let translations = ProtocolsEditor.Application.Persistence.Translations.loadFromDirectoryOf path
        ProtocolsEditor.Application.Repositories.Translations.initializeRepo translations |> ignore

How?

Data types

  • Algebraic data types
  • Product types
  • Immutable types

The road to F#

Let's begin with some inocuous C# code

1:
2:
3:
4:

private bool Launch(Missiles m)
{
    ThereIsNoPeopleArround() && m.Launch();
}
(Mostly inocuous.)
At least the method is private!

anyway...

How && works?

&&

from A and B the computer can calulate A&&B

(no rocket science, at this point)

but...

this is the same as saying that A&&B is

  • B if A succeeds,
  • and is false otherwise

so

1:

ThereIsNoPeopleArround() && m.Launch();
  • if && had not short-circuited the evaluation,
  • independently of the value of ThereIsNoPeopleArround()

the missiles will have been launched

:(

ROP type

1:
2:
3:

type Result<'a,'b> =
    | Success of 'a
    | Failure of 'b

Interlude: function composition

\(f: A \mapsto B\)

\(g: B \mapsto C\)

then

\(h: A \mapsto C\)

where

\(h(x) = (g \cdot f)(x) = g(f(x))\)

(I'm sorry I had to)

Now in code

1:

let compose f g x = f (g x)

then when we have 2 particular f & g

1:
2:

let h = compose f g
let a = h 3

1:
2:
3:

let comose f g x = f (g x);;

val comose : f:('a -> 'b) -> g:('c -> 'a) -> x:'c -> 'b

We don't like to write compose

1:

let (>>) g f x = f (g x)

or point free style

1:

let (>>) g f = compose f g

then when we have 2 particular f & g

1:
2:

let h = g >> f
let a = h 3

We don't like to lose the meaning of what we're doing

the idiomatic F# uses pipes instead

1:

let a = 3 |> g |> f

Pipe

1:

x |> f = f x

Reverse pipe

1:

f <| x = f x

WAT?!

Precedence is important, look:

1:
2:
3:
4:
5:
6:

checkNotExists "this protocol already exists"
    >=> createProtocol
    >=> checkIntegrity "data integrity error, there are parameters with incorrect protocol information"
    >=> prepareChanges
    >=> Utils.applyChanges "unable to create protocol"
    >> Utils.log "created protocol" "protocol not created:" <| par

&& + composition = >=>

 1:
 2:
 3:
 4:
 5:
 6:
 7:
 8:
 9:
10:

module ROP =

    type Result<'a,'b> =
        | Success of 'a
        | Failure of 'b

    let (>=>) f g x =
        match f x with
          | Success s -> g s
          | Failure f -> Failure f

Use case

Shared resource

  • ProtocolInformation.xml (14M) +
  • ~60 .resource files
that needs to be updated safely
  • no concurrency
  • and no conflicts
  • and all the files at once.

Solution

Single api to update the system that provides optimistic concurrency + error reporting in the failing case.

The ideal case would be to be able to
  1. Check if there is any concurrency issue
  2. Validate interity of the data
  3. Validate integrity of the translations
  4. Update the data
  5. Log everything that happened or failed and report errors

Implementation

From an implementation point, the solution materializes in a SPA application that actually is a thin layer of a WebAPI.

Enter F# magic

 1:
 2:
 3:
 4:
 5:
 6:
 7:
 8:
 9:
10:
11:
12:

open ProtocolsEditor.Application.UseCases
open ProtocolsEditor.Infrastructure.Utils

[<RoutePrefix("api/protocols/{boardTypeId}/{boardSubTypeId}")>]
type ProtocolController() =
    inherit ApiController()

    /// Replaces the current protocol with the posted protocol
    [<HttpPut>]
    [<Route("")>]
    member x.Put(t: int, s: int, ps: Protected<Api.TranslatedProtocol>) =
        Protocols.updateParameters t s ps |> Utils.asResponse <| x.Request

 1:
 2:
 3:
 4:
 5:
 6:
 7:
 8:
 9:
10:

let updateParameters (t:int) (s:int) (tps:Protected<Api.TranslatedProtocol>) =

    checkHash "concurrency error, someone changed the same protocol while you were editing it"
    >=> checkIntegrity "data integrity error, there are parameters that are not from this protocol"
    >=> validateIdentifiers
    >=> checkTranslationKeyNotDefault DEFAULT_TRANSLATION_KEY (sprintf "%s is not a valid TranslationKey" DEFAULT_TRANSLATION_KEY)
    >=> checkTranslationKeysUniques "duplicated TranslationKey in this protocol"
    >=> prepareChanges
    >=> Utils.applyChanges "unable to apply changes"
    >> Utils.log "prot updated" "prot not updated:" <| (t, s, tprot)

Domain Model

(images/class-diagram) == record types

 1:
 2:
 3:
 4:
 5:
 6:
 7:
 8:
 9:
10:
11:
12:

namespace ProtocolsEditor.Domain.Model

module Protocols =

    open System
    open System.Xml.Serialization

    type ProtocolInformation = {
        LastUpdate: DateTime
        Parameters: ProtocolParameterInformation list
        Sensors: ProtocolParameterInformation list
    }

 1:
 2:
 3:
 4:
 5:
 6:
 7:
 8:
 9:
10:
11:
12:
13:
14:
15:
16:
17:
18:
19:
20:
21:
22:
23:
24:
25:
26:
27:
28:

namespace Definitions.Common.Domain
{
    using System;
    using System.Collections.Generic;
    using System.Xml.Serialization;

    [Serializable]
    [XmlRoot(Namespace = "www.foobar.com/protocols")]
    public sealed class ProtocolInformation
    {
        public ProtocolInformation()
        {
            this.Parameters = new List<ProtocolParameterInformation>();
            this.Sensors = new List<ProtocolParameterInformation>();
        }
        [XmlElement]
        public DateTime LastUpdate { get; set; }

        [XmlArray("Parameters")]
        [XmlArrayItem("Parameter")]
        public List<ProtocolParameterInformation> Parameters { get; set; }


        [XmlArray(ElementName = "Sensors")]
        [XmlArrayItem(ElementName = "Sensor")]
        public List<ProtocolParameterInformation> Sensors { get; set; }
    }
}

 1:
 2:
 3:
 4:
 5:
 6:
 7:
 8:
 9:
10:
11:
12:
13:
14:
15:
16:
17:
18:

type ProtocolParameterInformation = {
     Behavior: int
     BoardSubtypeId: int
     BoardTypeId: int
     DefaultGraphicRender: int
     FilterDefinitionInformation: FilterDefinitionInformation option
     IsComputed: bool
     IsPVPortalComputed: bool
     MainParameter: bool
     Mode: int
     ParameterOutputMode: int
     ProtocolParameterIdentifier: int
     PVPortalComputeOperation: int
     Tipus: int
     TranslationKey: string
     TranslationResourceName: string
     ViewModeType: int
}

 1:
 2:
 3:
 4:
 5:
 6:
 7:
 8:
 9:
10:
11:
12:
13:
14:
15:
16:
17:
18:
19:
20:
21:
22:

type FilterDefinitionInformation = {
     CoefficientEvaluation: int
     ComputedReferenceClassName: string
     DailyGrouping: int
     DailyPeriod: int
     DecimalPlaces: int
     GraphicRender: int
     InstantaneousGrouping: int
     InstantaneousPeriod: int
     InvalidValues: int list
     IsSpecialFormat: bool
     MainCoefficient: double
     MeasureUnit: string
     MonthlyGrouping: int
     MonthlyPeriod: int
     ParameterSubType: int
     ParameterType: int
     SecondCoefficient: double
     SpecialFormatMode: int
     TranslationTableInformation: TranslationTableInformation option
     YearlyGrouping: int
}

 1:
 2:
 3:
 4:
 5:
 6:
 7:
 8:
 9:
10:

type TranslationTableDetailInformation = {
     Key: double
     TranslationKey: string
}

type TranslationTableInformation = {
    TranslationResourceName: string
    TranslationTableInformations: TranslationTableDetailInformation list
    TranslationTableTypeFullName: string
}

1:
2:
3:
4:
5:

type Board = {
    BoardTypeId: int
    BoardSubtypeId: int
    ParameterIds: int list
}

Theory

  • Inmutabilty by default (actually, no mutable field used in this editor!)
  • Functional

Practice

  • You need to mutate things: Lenses
  • You need some objects

I <3 F#

F#
